Item number: Orbisfly®Pro25 (Winch 25 + Power and Cat6+HDMI(customize))
Lifting capacity: 25 kg (55.1 lb)
Lifting height: 12 m (40 ft)
Lifting speed: 120 cm/s (47.2 in/s)
Through Connection - Input: Neutrik powerCON TRUE1 & EtherCON (F)
Through Connection - Output: Neutrik powerCON TRUE1 & EtherCON (M)&XLR3&XLR5&HDMI(customize)
Through Connection - Power: 6A/240 VAC or DC (class II) 2x1.0mm2 (AWG18)
Through Connection - Signal: Four twisted pairs Cat6 (5120 Mbit/s)
Ethernet: 5120 Mbit/s (Four twisted pairs)
Voltage: 200-240 VAC (110V need customized)
Frequency: 50-60 Hz
Power consumption: 750 W (5.5-7.9 A)
Power inlet: Neutrik powerCON TRUE1 NACPX (F/M)
DMX control signal: DMX 512 1990+DMX512A
DMX channels: 4/5
DMX control connection: 3/5 Pole XLR (F/M)
Fleet angle: None
Minimum load: 2 kg (4.4lb)
Noise emission: ≈40 dB at 1m (3.3 ft)
Ambient temperature: 5-40 °C (41-104 °F)
Mounting clamp: 2 x Slim eye coupler 42-52 mm (2 in)
Motor: 230 VAC, 750 W Servo Motor
Weight: 35.4 kg (78.04 lb)
