The winch hang laser lights: https://youtube.com/shorts/nv5EnRH_cY8?si=qHppS9Y90bfnBKFs
The winch hang LED screen: https://youtube.com/shorts/RAjstWXV2X0?si=tfQcqtLhSqA4F0VD
The winch hang moving head lights :https://youtube.com/shorts/rBlNj5amBGE?feature=share
The winch hang bar lights: https://youtube.com/shorts/HWZpTujwkaY?si=zbOfTFIjkKZhydE8
Lifting capacity: 25 kg (55.1 lb)
Lifting height: 6m (20 ft)
Lifting speed: 120cm/s (47.2 in/s)
Through Connection - Input: Neutrik powerCON TRUE1 & EtherCON (F)
Through Connection - Output: Neutrik powerCON TRUE1 & EtherCON (M)&XLR3&XLR5&HDMI（customize）
Through Connection - Power: 5A/240V AC or DC (class II) 2x2x0.5mm2 (AWG18)
Through Connection - Signal: Two twisted pairs Cat6 (1000 Mbit/s)
Ethernet: 1000 Mbit/s (two twisted pairs)
Voltage: 110/240V AC
Frequency: 50-60 Hz
Power consumption: 750 W (2,4-2,1 A)
Power inlet: Neutrik powerCON TRUE1 NACPX (F/M)
DMX control signal: DMX 512 1990+DMX512A
DMX channels: 4/5
DMX control connection: 3/5 Pole XLR (F/M)
Fleet angle: None
Minimum load: 2 kg (4.4lb)
Noise emission: ≈40 dB at 1m (3.3 ft)
Ambient temperature: 5-40 °C (41-104 °F)
Mounting clamp: 2 x Slim eye coupler 42-52 mm (2 in)
Motor: 230 VAC, 0.75 kW Servo Motor
Weight: 28 kg (61.7 lb)
