Lifting capacity: 50 kg (110.2 lb)
Lifting height: 12m (40 ft)
Lifting speed: 60cm/s (3.5-23.6 in/s)
Through Connection - Input: Neutrik powerCON TRUE1 & EtherCON (F)
Through Connection - Output: Neutrik powerCON TRUE1 & EtherCON (M)&XLR3&XLR5&HDMI（customize）
Through Connection - Power: 6A/240 VAC or DC (class II) 2x1.0mm2 (AWG18)
Through Connection - Signal: Four twisted pairs Cat6 (5120 Mbit/s)
Ethernet: 5120 Mbit/s (Four twisted pairs)
Voltage: 200-240 VAC (110V need customized)
Frequency: 50-60 Hz
Power consumption: 750 W (5.5-7.9 A)
Power inlet: Neutrik powerCON TRUE1 NACPX (F/M)
DMX control signal: DMX 512 1990+DMX512A
DMX channels: 4/5
DMX control connection: 3/5 Pole XLR (F/M)
Snap hook: 2x8 mm (5/16 in) galvanized steel w/Bar 652 mm (25.2 in)
Fleet angle: None
Minimum load: 5 kg (11.02 lb)
Noise emission: ≈50 dB at 1m (3.3 ft)
Ambient temperature: 5-40 °C (41-104 °F)
Mounting clamp: 4 x Slim eye coupler 42-52 mm (2 in)
Motor: 230 VAC, 0.75 kW Servo Motor
Lifting wire: 3 mm (1/8 in) 19x7 galv. steel wire (EN 12385-4)
Minimum wire breaking load: 588 kg (5766 N / 1296 lb)
Wire safety factor: >10
Expected wire lifetime - 10 kg (22 lb) load: Pending
Expected wire lifetime - 20 kg (44.1 lb) load: Pending
Expected wire lifetime - 40 kg (88.2 lb) load: Pending
Shipping weight: 55 kg (121.2 lb)
Weight: 60 kg (132.3 lb)
