Cuelight use for PowerPoint Presentation
1. Local Control
► [Next page] 、●[Turnoff the screen]、◄ [Previous page]
2. MASTER & SLAVE switch
MASTER (Set MASTER) 、 SALVE (Set SALVE)
NOTE: When multiple devices are connected by wire, set the one closest to the remote as
master, set the others as slaves so that only the master receives the signal from the transmitter.
3. SOUND switch
Control speaker volume: HI (high volume), LO (low volume), OFF (off)
4. LIGHT switch
Control brightness: HI (highlight), LO (low light), OFF (off)
5. USB 1& 2&3&4
Without restarting, connect or disconnect the USB, remote control demoSoftware.A total of 4 computers can be connected at the same time. Driver free support for
MAC OS and WINDOWS system. Plug and play
6. USB Port
For direct connection with the computer, the computer can supply power to
the equipment.Device transmitting modeMimic keyboard commands "Next page",
"Turn off Screen" and "Previous page", thus preserving Leave mouse function.
7. RJ45 port
Devices are interconnected using network cables. For simultaneous control of
two receivers. Cannot connect to the network switches!!
8. Output 3.5mm headphone Port
The stereo jack output corresponds to "Forward", "backward" and "black screen" sound effects.
