LED Moving head
3715 Zoom&Rotation

ES-ML28  3715 Zoom&Rotation

Optics and light source

.Zoom System :10°-50°(Structure Patent:ZL2015 2004 3557.3)
.Highly efficient lens system
.37 RGBW multichip LED max. 15W
.Round beam without gaps between the lenses
.Lens rotation

Effects
.Beam color mixing: RGBW
Power consumption
.Input Voltage: AC 100-240V, 50/60Hz
.Power Consumption:  600W

Control Channels: 11/16/22/38
Fan speed:Automatically adjust cooling-fan
On-board: LCD screen
Movement:
.High resolution 3 phase stepping motors
.Precise and fast movement
.Low-noise, suitable for sound-sensitive
.Pan/Tilt: 540°/ 270°
.Pan/Tilt Resolution: 16 bit

.2x Omega brackets for quick and comfortable
.3pin and 5pin connectors
.Powercon Socket:Powercon in/out
.Net Weight: 15.8 kg
.Dimensions: 324 x 203 x 390mm

Certification: CE, RoHS and SGS
Features
Download

ES-ML28  3715 Zoom&Rotation

Optics and light source

.Zoom System :10°-50°(Structure Patent:ZL20152004 3557.3)

.Highly efficient lens system

.37 RGBW multichip LED max. 15W

.Round beam without gaps between the lenses

.Lens rotation



Effects

.Beam color mixing: RGBW

Power consumption

.Input Voltage: AC 100-240V, 50/60Hz

.Power Consumption:  600W



Control Channels: 11/16/22/38

Fan speed:Automatically adjust cooling-fan

On-board: LCD screen

Movement:

.High resolution 3 phase stepping motors

.Precise and fast movement

.Low-noise, suitable for sound-sensitive

.Pan/Tilt: 540°/ 270°

.Pan/Tilt Resolution: 16 bit



.2x Omega brackets for quick and comfortable

.3pin and 5pin connectors

.Powercon Socket:Powercon in/out

.Net Weight: 15.8 kg

.Dimensions: 324 x 203 x 390mm



Certification: CE, RoHS and SGS
